Introduction:

Xeos Technologies Inc., founded in 2004, is committed to combining diverse and mature technologies to develop world leading wireless telemetry products. The three founders of Xeos have over 60 years of combined experience in electronic engineering, mechanical engineering, software development, and manufacturing. Xeos' products include deep-sea beacons, surface oil spill tracking systems, and ground perimeter monitoring systems. Xeos is also an Iridium value-added service agent and can provide contracted technical services in addition to their standard product line. All of these traits have brought success to Xeos in four areas: communication, ocean equipment recycling, remote monitoring, and protection.

XMF-11K Remote Head Underwater LED Light Beacon

XMF-11K Remote Head Beacon Introduction:

The XMF-11K Remote Head is an optional split structure of XMF, providing great flexibility while maintaining all the functions of a standard XMF beacon. The XMF-11K Remote Head is powered by a waterproof cable connected to a 4-pin connector, ensuring strong endurance. At the same time, it is equipped with 6 AA alkaline batteries that can continue to be used even if the instrument is powered off.

Main features of XMF-11K Remote Head:

1. The entire beacon design is compact and small

2. Titanium alloy shell, maximum pressure resistance 7500m

3. Microprocessor control, ultra high brightness LED flash, multiple colors to choose from

4. Low power consumption, optional external power supply, suitable for long-term deployment

5. Multiple activation options: magnetic switch, tilt switch, and solid-state surface sensor switch

6. Users can choose to change the LED flashing frequency of the beacon

XMF-11K Remote Head Technical Parameters

Electrical specifications:

Power supply: 6 AA alkaline batteries

Optional long or short casing or external power supply 7V-36V

Running time: 547 days for underwater deployment

160 days of water release (flashing every 30 seconds)

Switch control: Magnetic reed switch, can be activated without opening the instrument

Solid state tilt switch, vertical activation or deactivation

All methods are switched on the PCB board

Flashing options: 1, 2, or 3 flashes per cycle are optional

10 selectable cycle settings (1-30s)

LED specifications:

LED： 4.13 watts, single tube type

Luminous flux: Amber: 100 lumens;

White: 70 lumens

Mechanical specifications:

Size: Head length x diameter: 19.5cm x 2.87cm

Tube length x diameter: 45.41cm x 2.87cm

Weight:

(Alkaline battery) 1010g (in water); 1525g (in air)

(Lithium battery) 955g (in water); 1470g (in air)

Material: Grade 9 titanium alloy

End cap: screw knob, O-ring seal

Lens: Glass material

Environmental specifications:

Working temperature:- 40°C—60°C

Voltage resistant depth: 7500m

XMF-11K underwater LED beacon is specially designed for deep-sea applications, with a pressure resistance of 11000m
