Introduction:

Xeos Technologies Inc., founded in 2004, is committed to combining diverse and mature technologies to develop world leading wireless telemetry products. The three founders of Xeos have over 60 years of combined experience in electronic engineering, mechanical engineering, software development, and manufacturing. Xeos' products include deep-sea beacons, surface oil spill tracking systems, and ground perimeter monitoring systems. Xeos is also an Iridium value-added service agent and can provide contracted technical services in addition to their standard product line. All of these traits have brought success to Xeos in four areas: communication, ocean equipment recycling, remote monitoring, and protection.

XMA-11K Underwater Argos Satellite Beacon

XMA-11K（11000m）

XMA-11K Beacon Introduction:

XMA-11K is an independently powered, self-sustaining underwater Argos satellite beacon that can dive to a depth of 11000m. This beacon can protect your valuable underwater instruments and facilitate recycling. The XMA-11K beacon has a sturdy titanium alloy casing and a solid-state surface sensor, which is small in size but powerful in functionality.

Main features of XMA-11K:

1. The miniaturization design of the entire beacon

2. Titanium alloy shell, maximum pressure resistance 11000m

3. Users can choose to change the transmission frequency of the beacon

4. Solid state surface sensor

5. Low power consumption, suitable for long-term deployment

6. Global coverage through Argos system signal

7. Optional split structure: XMA-11K Remote Head model

XMA-11K Technical Parameters

Functional features:

Basic function: Fully compatible with Argos PTT platform transmitting terminal

Serial Programming: User ID, Repetitive Cycle, Transmission Frequency, Data Information

Electrical specifications:

Power supply: Standard long shell: 6 AA alkaline batteries

Optional short shell: 7 CR123A lithium batteries

Running time:>96 days, sending interval of 90s (default setting)

RF specifications:

RF output power: 1W

Antenna output impedance: nominal 50 ohms

Channel: 401.63-401.656MHz (optional for users)

Programming interface:

Serial interface: 9600 baud rate, TTL level

Mechanical specifications:

Standard long casing (without antenna):

Size: Length x Diameter: 43.66cm x 2.87cm

Weight: 652g (in water); 921g (in air)

Optional short casing (without antenna):

Size: Length x Diameter: 38.2cm x 2.86cm

Weight: 431g (in water); 644g (in air)

Material: Grade 9 titanium alloy

Environmental specifications:

Working temperature:- 40°C—60°C

Pressure resistant depth: 11000m

The XMA-11K underwater Argos satellite beacon is specifically designed for deep-sea applications, with a pressure resistance of 11000m
