XL-60C Traditional Chinese Medicine Grinder
XL-60C Traditional Chinese Medicine Grinder
Product details
1、 Product Name and Model
1. Product Name:High efficiency crusher
2. Machine model parameters
| model | XL-60C | Voltage: | 220V |
| Power: | 2800W | Motor speed: | 5200r/min |
| Production: | 10-50kg/h | Fineness: | 60-200 mesh |
| Machine weight: | 52kg | External dimensions: | 24×85×40cm |
2、 Scope of use
Efficient crusherIt can quickly crush various soft and hard medicinal materials and other materials, mainly including Ganoderma lucidum, American ginseng, iron maple, Panax notoginseng, pearls, stems and grasses, minerals, grains and cereals, maca, dried herbaceous plants, etc. (oilyExcept for wet and viscous materials. Note: The size of the block material to be directly input cannot exceed 40 millimeters.
IIIHigh-efficient pulverizerWorking principle
The material enters the crushing chamber through the feeding hopper and feeding port, and is initially crushed in the first crushing chamber through relative motion between the rotating toothed disc and the stationary toothed disc. The initially crushed material is discharged through the discharge hole of the rotating disc
Placed in the second crushing chamber (outer crushing chamber), there is a high-speed rotating hammer head inside the outer crushing chamber. The high-speed rotating hammer head and the internal gear ring inside the crushing chamber move relative to each other and undergo impact, tearing, and rubbing effects
Crush the material and discharge it into a collection bag (or box) through a sieve under the action of centrifugal force.
Crush the material and discharge it into a collection bag (or box) through a sieve under the action of centrifugal force.
