1、 Product Overview

The rubber industry is one of the important basic industries of the national economy. With the continuous development and progress of the rubber industry, I The company has developed and produced an automatic rubber edge removal machine based on the needs of rubber manufacturers. The rubber automatic edge removal machine adopts aerodynamics The principle is to separate rubber products from burrs through a series of high-speed rotations and collisions.

IISuitable materials:

Rubber, silicone rubber, nitrile rubber, chloroprene rubber, natural rubber, fluororubber, EPDM rubber Rubber materials other than recycled rubber, such as rubber, polyurethane rubber, chloroether rubber, acrylic rubber, etc. n

Suitable for the deburring operation of all rubber seals and other rubber miscellaneous parts after molding, and can directly remove the edges and mold rubber products. Detachable edge asO-ring YRings, gaskets, rubber plugs, rubber particles, solid shaped rubber parts or wall thicknesses 2 More than one millimeter, hair Side by side0.1-0.2Various rubber products within millimeters, free of metal, with a cutting edge (also known as a cutting mouth). advantageAdvantage

3、 Product Features

Integrating good performance, high output, and higher efficiency, it perfectly replaces traditional manual, freezing, and punching processes, Enhance the image and competitiveness of the enterprise.

●High production efficiency:The daily processing capacity of a rubber automatic edge removal machine is equivalent toThe hook edge workload of 30-50 skilled workers (the smaller the rubber product, the greater the production capacity, especially suitable for products with an outer diameter of 5mm-80mm). The rubber edge removal machine can automatically control the edge removal speed and time, making the entire operation process intelligent. The work efficiency is 40-50 times that of manual operation. One machine can remove more than 10 million small rubber rings in 10 hours, with a separation rate of over 99%. The processed products are not deformed or damaged.

●Automatic edge removal machine with stable edge removal quality:The precision and qualification rate of edge removal are significantly higher than those of manual operation (traditional manual hook and burr operation is slow There are serious issues such as excessive burrs, scratches, scratches, mixed goods, and dirt.High edge removal rate, achievable99%Above, there is no deformation, damage, or detachment Color issues have reduced waste.

●High cost-effectiveness:Low usage cost, with an hourly power consumption of less than4 degrees, does not require the use of liquid nitrogen, and the equipment price is significantly lower than that of frozen hair trimming machines or imported equipment. Processing any rubber product without the need for molds and with higher efficiency than stamping to remove burrs

●Easy to operate:The operation interface is simple and clear, the operation steps are convenient, and it is easy for workers to perform edge removal operations more accurately and safely. need not Training is sufficient for employment.Processing different products does not require changing molds, and continuous assembly line operation of rubber edge removal can be achieved.

●Safe and reliable:The equipment is equipped with circuit protection devices, ensuring the safety of both the equipment and operators, and avoiding unnecessary incidents.

●Beautiful appearance:The equipment is spray painted as a whole, with optional colors, small size, easy to move, small footprint, and space saving.

●Quality assurance:Bearings used in JapanNSKThe motor brand is Siemens from Germany, a major brand that guarantees equipment quality, making your use more reassuring. workflowworkflow

The rubber automatic edge removal machine adopts the centrifugal principle, and there is an automatically controlled rotating disk inside the cylinder to drive the rubber product to rotate at high speed and constantly collide Strike to separate the burrs and rubber products from each other, thus achieving the function of removing burrs. The rubber edge removal machine adopts a one-time edge removal process. First, place the rubber parts that need to be removed into the working chamber (take an appropriate amount)5-15kg）， Cover the compartment door and start the equipment. The internal parameters of the device run, and after completion, open the discharge port to unload. End this edge removal.

4、 Product parameters

supply voltage380V/50HZ

Motor Power3kw

Equipment dimensions (mm)）1400*595*1100

Mpa0.6-0.8mpa

Equipment weight350KG

Assembly capacity5-10KG

Separation rate≥99%

TimeModel 5-15/minute

Painting color Light gray (can be customized according to customer requirements)
